BMC64 | BMC128 | BMVIC20 | BMPLUS4 | BMPLUS4EMU (Pi3)BMPET

NOTE: BMPLUS4 is now bundled with BMC64 v3.0+

Download the universal image from the BMC64 main page.

BMPlus4 is a bare metal Plus/4 Emulator (using VICE) for the Raspberry Pi (Models 2 & 3). There is no bloated O/S to boot and the emulator has direct access to hardware resulting in better performance than the Linux based distributions. VICE dependencies are satisfied using circle-stdlib.

BMPLUS4 Setup

  • Setup is simlar to BMC64 except the ROM files are different and must reside in a PLUS4/ directory:
    		    /PLUS4
    		       kernal
    		       kernal.005
    		       kernal.232
    		       3plus1hi
    		       3plus1lo
    		       basic
    		       c2lo.364
    		       d1541II (optional)
                           dos1551 (recommended)
    		       rpi_sym.vkm
                           bootstat.txt

    The emulator will not run without them. These are available from many sites.

    • Example

      NOTE: You will have to rename some of the names you find here to the names the emulator expects above.
